FibraMat™FibraMat™ is a durable, non-hazardous, nonwoven synthetic fiber product manufactured as a worker and consumer-friendly alternative to fiberglass. Its unique manufacturing process allows it to be engineered to meet a wide variety of requirements. It is an excellent thermal and acoustical insulator, and it is also very effective as polyiso foam gasketing.

A Non-hazardous, Nonwoven Alternative to Fiberglass

FibraMat™ is a UL Recognized Component to 94-HF1 and passes MVSS 302 test for flammability. It is 100% recyclable, hypoallergenic, mold and mildew resistant and has no noticeable odor. In addition, it is non-absorbent and will not deteriorate or lose dimensional stability when exposed to moisture. It can be laminated with films, scrims, foils, fabrics and pressure sensitive adhesives.

FibraMat™ Components made from FibraMat™ are ideal for OEM manufacturing and assembly facilities. It is environmentally friendly and does not require the use of respirators, protective clothing or other safety precautions associated with the exposure to fiberglass.

Several standard configurations are available or RubberMill can develop a custom product or composite to meet your specific requirement. Contact us today to discuss your requirements. FibraMat™ will be an excellent addition to your list of Green, Worker Friendly initiatives.



General Specifications for FibraMat™:

  • Common Thickness Range (inches) .25 – 4
  • UL Recognized Density Range (lb/cf) .76 – 3.0
  • Maximum Continuous Use Temperature 180° F, ASTM C 411
  • Maximum Continuous Use Temperature

Thermal Resistance Examples,
ASTM C518 (R-Value typical results):

  • 2” thick, 1 lb/ft³ — 6.2 ft².hr.° F/Btu
  • 1.25” thick, 1.1 lb/ft³ — 3.85 ft².hr.° F/Btu
  • 1” thick, 1 lb/ft³ — 3.3 ft².hr.° F/Btu
  • 0.5” thick, 1 lb/ft³ — 1.5 ft².hr.° F/Btu

Fabrication Capabilities for FibraMat™:

  • Die Cutting
  • Die-less cutting
  • Kiss Cutting
  • Hinge Cutting,Slitting
  • Pressure Sensitive Adhesive Coating/Application
  • Composite Lamination
  • Facings and Backings
  • Thermoforming
  • Ultrasonic Welding

Typical Markets Served:

  • Appliance
  • HVAC
  • Restaurant Equipment
  • Automotive / Transportation

Material Comparisons

FibraMat™

  • 100% recyclable
  • Excellent acoustical properties
  • Excellent resilience
  • Excellent thermal properties
  • Excellent anti-fogging properties
  • Excellent dimensional stability
  • Excellent abrasion resistance
  • Non-absorbent
  • Hypoallergenic
  • Bacteria and mildew resistant
  • No noticeable odor

Fiberglass

  • Can cause skin irritation
  • Respiratory irritant
  • Non-recyclable
  • Contains formaldehyde binders
  • Poor abrasion resistance
  • Fair acoustical properties
  • Harbors bacteria
  • Poor resilience and stretch
  • Retains water and odor
  • Requires safety labeling

Looking for something else?

Many other nonwoven fiber products are available from RubberMill, including:

  • Synthetic polymer gray-black thermal/acoustic nonwovens
  • Fire retardant treated reclaim nonwovens
  • Needled polyester, Polypropylene and needled wool felts
  • High Temperature FibraMat™ 350° F, ASTM C 411

You can also read more about all our other materials here.
